450/750V BV 300mm2 Single Core Solid Copper PVC Insulated Electrical Wire IEC 60228

Applications

Ideal for fixed laying in indoor conduits, cable trays and distribution rooms. Widely applied for main power wiring of industrial equipment, commercial buildings, residential projects and low-voltage complete electrical devices. Suitable for 450/750V AC power distribution systems for heavy-load power transmission.

Product Features

Built with high-purity solid copper conductor for stable large-current transmission and low power loss. Uniform PVC insulation provides reliable electric insulation, moisture resistance and mechanical protection. Simple structure, easy stripping and terminal connection. Excellent ageing resistance and safety performance for long-term stationary installation.

Item	Specification
Model	BV 450/750V 300mm²
Rated Voltage	450/750V AC
Conductor Material	High-purity Solid Copper
Insulation Material	PVC
Nominal Cross Section	300mm²
Max. Long-term Working Temperature	70℃
Minimum Bending Radius	8× Wire Outer Diameter
Reference Outer Diameter	22.5mm
Reference Weight	2780kg/km
Installation Type	Fixed Indoor Wiring Only

Why Choose Zhenglan Cable:

• OEM/ODM services provided
• Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
• Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
• Registered capital of $30 million and factory covers an area of 60,000㎡
• Advanced test equipment and procedures, 100% inspection before factory
• Enough stocks and the higest efficient shipping time guarranteed
• Professional pre-sales and after-sales services provided
