Product Description:
Tree wire is self-supporting covered conductor that is used in place of bare conductor in overhead primary distribution. Tree wire is used to reduce outages in areas where there is potential for incidental contact with tree limbs.
Conductors are concentrically stranded, AAC (1350-H19), either compressed or full compact depending on conductor size, AAAC or ACSR. Available with high-density track-resistant polyethylene (HDTRPE) or Track-Resistant Crosslinked Polyethylene (XLPE) covering.
Conductor:
AAC- compressed stranding, 1350-H19 aluminum made to ASTM B231
AAAC- concentric stranding, 6201-T81 aluminum alloy made to ASTM B399
ACSR- Stranding concentrico, aluminio 1350-H19 con nucleo de acero GA2 hecho a ASTM B232
Coverings:
High-Density Polyethylene (HDPE)
Cross-Linked Polyethylene (XLPE)
Voltage:
15kV, 25kV, 35kV
Technical Parameters:
| Size |
No.of Wires |
Covering Thickness |
Cable Diameter |
Rated Strength |
Weight |
| (AWG or kcmil) |
No. |
Conductor Shield(mm) |
Inner Layer(mm) |
Outer Layer(mm) |
mm |
kN |
kg/km |
| 3-Layer 25kV ACSR/XLPE/HDPE |
| 1/0 |
6/1 |
0.38 |
3.18 |
3.18 |
23.6 |
19.4 |
586 |
| 2/0 |
6/1 |
0.38 |
3.18 |
3.18 |
24.7 |
23.3 |
666 |
| 3/0 |
6/1 |
0.38 |
3.18 |
3.18 |
25.8 |
29.4 |
763 |
| 4/0 |
6/1 |
0.38 |
3.18 |
3.18 |
27.5 |
37.1 |
891 |
| 266.8 |
18/1 |
0.38 |
3.18 |
3.18 |
28.6 |
30.3 |
913 |
| 336.4 |
18/1 |
0.38 |
3.18 |
3.18 |
30.1 |
38.2 |
1058 |
Image:
Packing and Shipping:
The Overhead Insulated Cable is carefully packaged to ensure maximum protection during transportation and handling. Each cable reel is securely wound and wrapped with a protective layer to prevent damage from moisture, dust, and mechanical impact.
Packaging materials include sturdy wooden reels or drums, reinforced with metal bands to maintain structural integrity. Additionally, the cable ends are sealed with plastic caps to avoid contamination and preserve insulation quality.
For shipping, the packaged cables are loaded onto pallets or containers with proper securing methods to prevent movement and abrasion. Handling instructions and safety labels are clearly marked on each package to guide transportation personnel.
We ensure compliance with international shipping standards to guarantee that the Overhead Insulated Cable arrives safely at its destination, ready for immediate installation and use.
FAQ:
Q1: What is the brand and model number of the overhead insulated cable?
A1: The overhead insulated cable is manufactured by Zhenglan Cable, and the model number is Medium Voltage Overhead Cables.
Q2: Where is the overhead insulated cable produced?
A2: The overhead insulated cable is produced in China.
Q3: What certifications does the Zhenglan Cable overhead insulated cable have?
A3: The cable is certified with CE, ISO, and CCC certifications.
Q4: What is the minimum order quantity for the overhead insulated cable?
A4: The minimum order quantity for the cable is 1000 meters.
Q5: How is the cable packaged for shipment?
A5: The cable is packaged in export wooden drums, iron wooden drums, or as per customer requirements.
Q6: What are the payment terms available for purchasing the overhead insulated cable?
A6: Payment terms include T/T, L/C, and Western Union.
Q7: What is the typical delivery time for the overhead insulated cable?
A7: Delivery time varies depending on the product type, size, and production construction. For more details, please contact us directly.
